Computerized Shuttleless Quilting Machine Non-Shuttle Multi-Needle Mattresses Quilting Machine
|
Product Details:
Payment & Shipping Terms:
|
Detailed Product Description
| Applicable Industries: | Manufacturing Plant | Showroom Location: | Egypt, Turkey, Pakistan, South Africa |
|---|---|---|---|
| Video Outgoing-inspection: | Provided | Machinery Test Report: | Provided |
| Marketing Type: | Hot Product 2019 | Warranty Of Core Components: | 1 Year |
| Core Components: | Bearing, Motor, Gear | Condition: | New |
| Place Of Origin: | Guangdong, China | Brand Name: | Yuxing |
| Max Sewing Speed: | 900 R/min | Max Sewing Thickness: | 80mm |
| Number Of Head: | Multi-needle | Moving Style: | Frame Moved |
| Voltage: | 380V Or 220V | Power: | 7 KW |
| Dimension(L*W*H): | 4800*1600*2000 Mm | Weight: | 5000 KG |
| Warranty: | 1 Year | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Speed: | 900 R/min | Computerized: | Adjustable |
| Motor: | Servo | Sensor: | Infrared |
| Maket Status: | Popular | Color: | Blue And White |
| Needle Bar: | 3 | Needle Bar Space: | 3''+3''*/2''+3'' |
| Needle Space: | 1'' | After Warranty Service: | Video Technical Support, Online Support, Spare Parts, Field Maintenance And Repair Service |
| Local Service Location: | Egypt, Turkey, Pakistan, South Africa | Certification: | CE ISO9001:2000 |
Computerized Non-Shuttle Multi- needle mattresses Quilting Machine
SERIAL NO.: YXN-94-3C
Quilting mattress/ bedding,cushion/ carpet/ duvet
FEATURES
* Needle bar is pushed by rocker arm that could dispense with lube which may stain upper material.
* Saddle frame and roller are driven by servo system.
* Three needle bars 3"+3" or 2"+3", which imported from Germany
* Endurable Bearing introduced fromJapan
* Sliding guide ensures smooth running,finer patterns and lower chance of breaking thread.
* Auto-stop when broken thread is tested by infrared senser.
* Needle bar will stay at the highest position after stopping machine.
* Micro-adjustment of pattern design by computer for better quilting appearance.
* Both continuous and jump patterns are capable of.
PARAMETERS
|
Model
|
YXN-94-3C (2" +3" /3" +3" )
|
| Size(L*W*H) | 5000*1600*2000mm |
| Weight | 5000kg |
| Quilting width | 2485mm |
| Needle bar spacing | 50.8, 76.2, (2" +3" ); 76.2, 76.2(3" +3" ) |
| Quilting thickness | 80mm |
| Rolling speed |
600-1200r/min |
|
Throuthput |
10-230m/hour |
| Needle type | #21-#24 |
| X-axis movement | 410mm |
| Needle spacing | 25.4mm |
| Stitch length | 2-8mm |
| Rated voltage(AC) | 380V/50HZ, /220V/60HZ |
| Power | 7KW |
Company Information
Yuxing Machinery Equipment Technology Co.,Ltd has been in quilting machine industry since 2000, mainly manufacture:
-- Computerized Lock stitch/Chain stitch Quilting Machine
-- Embroidery and Quilting Machine
-- Cutting Panel,Fabric Roller,Bobbin Winder etc with varied types
We improve R&D assiduously for our products to keep putting new upgraded machine on market,produce and finishing machine parts, manage sell, and provide after-sale service , all process involved
Machines is for producing mattress,sleepping bag,garments,bedspread,duvet,cushion and other home textile fashion goods.
Quality first/ Customer paramount/ Honest business/ Credit-founded
